Dongfeng DF285 PM 6x4 Prime Mover 2025 Price in Pakistan & Specs

Write a Review

New Dongfeng DF285 PM

Used Dongfeng DF285 PM

Engine

6700 cc

Horsepower

285 hp @ 2500 RPM

Torque

970 Nm @ 1500 RPM

Key Specifications of Dongfeng DF285 PM 6x4 Prime Mover

Diesel

285 hp @ 2500 RPM

2 Seats

Manual

Body Type

Truck

Drive Train

6x4

Key Features of Dongfeng DF285 PM 6x4 Prime Mover

Front Power Windows / Electric Windows

Anti Lock Braking System (ABS)

Air Conditioner

Dongfeng DF285 PM 2023 Models

Dongfeng DF285 PM 6x4 Prime Mover Brochure Specs and Features

See latest and brand new Dongfeng DF285 PM 6x4 Prime Mover full specs with all the features in detail.

DF 285	6X4 Prime Mover
Vehicle Weight
G.C.M (kg)	50,000
Curb Weight (Chassis)	7,500
Chassis Dimensions (mm)
Overal Chassis Length	6,960
Cab Width	2,500
Cab Height (Unladen)	3,390
Wheel Base	3,300+1,350
Front Overhang	1,500
Rear Overhang	810
Max. Speed	90 km/hr
Gradeability	20%
Frame Dimensions (mm)
Frame Width (Front)	860
Frame Width (Rear)	860
Frame Section Height	280
Frame Section Width	60
Clutch
Type	Dry Singe Plate
Diameter	430 mm (17 inch)
Operating System	Hydraulic Control with Air booster, pushing.
Engine
Make	Cummins
Model	ISDe285 30
Emission Level	Euro III
Max Power	285 hp at 2500 rpm
Max Torque	970 Nm at 1500 rpm
Displacement (lit)	6,700 CC
No. of Cylinders	6
System	Electronic control High-pressure common rail Fuel system water cooled turbo charged, air cooled.
Cylinder bore (mm)	107
Stroke (mm)	124
Gear Box / Transmission
Type	9JS119T-B DD
Number of Gears	9 forward Gears & 1 reverse syncronized
Axles
Make	DANA
Front	Elliot type I beam section
Load Capacity	7 tons
Rear	Single reduction
Load Capacity (ton)	11 + 11 Tons
Final Ratio	5.571
Suspension
Front	8 - Leaf Springs
Rear	13 - Leaf Springs
Brake System
Brake	Full Air Brake System, split pneumatic circuit, parking spring brake acting on rear axles, exhaust brake, ABS
Fuel Tank
Type	Aluminium fuel tank w. lockable cap
Capacity	400 ltrs
Cabin
Cabin	Kingrun one and a haf row cab, forward control hype, all welded steel cab of tilt type, manua cab tilt, rear mechanical cab suspension adjustable driver's seat with speed limiter. Air Conditioner system, electrical windows, central lock
Tyres
Front	Single
Rear	Dual
Size	11.00X20-18PR
Battery
Voltage (V)	24
Battery Capacity	140X2

Show More ▼Show Less ▲

Dongfeng DF285 PM 6x4 Prime Mover Specifications

Kerb Weight	7500 KG	No of Doors	2 doors
Overall Height	3390 mm / 11'2" feet	Overall Length	6960 mm / 22'11" feet
Overall Width	2500 mm / 8'3" feet	Wheel Base	3300+1350 mm / 10'10" feet
Ground Clearance	-

Cylinder Configuration	-	Displacement	6700 cc
Engine Power	285 hp @ 2500 RPM	Fuel System	High-Pressure Common-Rail Fuel
Torque	970 Nm @ 1500 RPM	Valve Mechanism	Turbocharged
Valves per Cylinder	-	Compression Ratio	-
Assembly	Local	Warranty	-
No of Cylinders	6	Fuel Grade	-
CO2 Emission	EURO III	Bore/stroke (mm)	107/124

Minimum Turning Radius	-	Steering Type
Power Assisted	-	Steering Switch	-

Tire / Tyre Size	11X20-18PR	Wheel Size	in
PCD	mm	Wheel Type

Mileage City	0 KM/LITER	Mileage Highway	KM/LITER

Fuel Tank Capacity	400 L

Gearbox	9-speed

Suspension	Front: 8 Leaf spring, Rear: 13 Leaf spring	City driveability (20-80 kmph)	-

Top Speed	90 KM/H	Drive Modes	-
Parking Sensors	-	Acceleration 0-100kmph	-
Headlights	-	Day Time Running Lights (DRL)	-

Brakes	Full air brake system, parking spring brake	Braking (100-0 kmph)	-
Braking (80-0 kmph)	-

Drive Type	Front/Four wheel drive	Drive Setup	Driver right
Brochure	Download	Waiting Time (Own)	-
Release Date	30 November -0001	Category	Work Related
Outer Door handle finish	-	Door Visor
Multi Information Combination	-	Seats, Armrests & Door Lining Inserts	adjustable air suspended driver’s seat, speed limiter, central locki
Interior Color	-	Insight Door Handles	-
AC Vent Knobs	-	Hand Brake Knob	-
Antenna	-	Inner Lights	-
Supervision Cluster / Driver Multi Information System	-

Sound System / Speakers	-	USB Charger	-
Infotainment / Funtainment System / Audio System	-
Axels	2	Licensed Weight	-

Comfort & Convenience

CoolBox	Cup Holders
Power Seats / Seat Adjustment	Remote Boot/Fuel-Lid
Steering Adjustment	Sun-Roof \| Moon-Roof	\|
Cruise Control	Keyless Entry
Power Mirror	Remote Keyless Entry
Heated Seats	USB and Auxillary Cable
Climate Control	Rear AC Vents
Steering Switches	Arm Rest
Multi Info	Optional Navigation
Vanity Mirror	Accessory Power Outlet
Seat Lumbar Support	Smart Access Card Entry
Voice Control	Steering Wheel Gearshift Paddles
Central Console Armrest	Tailgate Ajar Indicator / Trunk Warning
Power Windows	Wiper Tinted Glass
Traffic Jam Assist	Navigation System / GPS System
Rear Ventilation	Terrain Response System
Air Conditioner	Remote Trunk Opener / Tailgate
Fast Charging	Auto door lock with speed
Brake Override System (BOS) / Smart pedal	Smart Entry
Auto A/C	Wifi Hotspot
Voice Command	Dust & Pollen Air Filter / Air Purifier
Digital Clock	Outside Temperature Display
Smart Welcome System	Refrigerator Compartment
Cabin Watch	Cabin Talk
Adaptive Cruise Control	Lane Winker
Remote Windows / Smart Key Open Close

Interior

Defogger		Tachometer
Third Row Seats		Defogger
Rear Window Defroster		Folding Rear-Seat
Leather Interior		Rear Seat Headrest
Heater		Interior Lighting
Isofix Seat/ Child Seat		Front Map Lamps

Exterior

Alloy Rims		Leather Seats
Front Fog Lights		Leather Seats
Alloy Rims		Rear Window Wiper
Front Fog Lights		Adjustable Headlights / Headlights Leveling
Auto Wiper / Rain Sensing Wiper		Power Antenna
Removable/Convertible Top		Roof Carrier
Side Stepper		Outside Rear View Mirror Turn Indicators
Integrated Antenna		Chrome Grille
Tow Package		Chrome Garnish
Smoke Headlamps		Roof Rail
Heated Wing Mirror		Rear Spoiler
Outside Mirror		Spare wheel
Trunk LID Lining

Safety

Power Door Locks		Alarm System Anti-Lock
Brakes Fog lights		Immobilizer Key
Traction Control System TCS		Child Lock
Rear Power Windows / Electric Windows		Automatic Emergency Braking
Intelligent Speed Assist System		Lane Departure Warning
Rear Seat Belts		Electronic Brake Assist EBA
Tyre Pressure Monitor System RPMS		Vehicle Stability Control
Anti-Theft Device		Central Locking
Speed Alert		Crash Sensor
Hill Assist / Hill Hold Control / Downhill Brake Control (HHC/ HAC / DBC)		Anti-Pinch Power Windows
Blind Spot Monitor		Security System
Hill Descent Control		Automatic Headlamps/ Automatic Headlights
High Mount Stop Lamp		Electronic Parking Brake
Vehicle Stability Management		Driver Condition Monitor
Wade Sensing		Rear Pre-collision Monitor
3D Surround Camera		Road Sign Assist
Vehicle Running Recorder / Trip Recorder
