Dongfeng DF420 PM 6x4 Prime Mover 2025 Price in Pakistan & Specs
Engine
11120 cc
Horsepower
420 HP
Torque
2050 Nm
Key Specifications of Dongfeng DF420 PM 6x4 Prime Mover
420 HP
2 Seats
Manual
Body Type
Air bag's driver seat
6x4
Key Features of Dongfeng DF420 PM 6x4 Prime Mover
Dongfeng DF420 PM 6x4 Prime Mover Brochure Specs and Features
See latest and brand new Dongfeng DF420 PM 6x4 Prime Mover full specs with all the features in detail.
DF 420
|
6X4 Prime Mover
|
Vehicle Weight
|
|
G.C.M (kg)
|
60,000
|
Curb Weight (Chassis)
|
9,000
|
Chassis Dimensions (mm)
|
|
Overal Chassis Length
|
6,960
|
Cab Width
|
2,500
|
Cab Height (Unladen)
|
3,770
|
Wheel Base
|
3,300+1,350
|
Front Overhang
|
1,500
|
Rear Overhang
|
810
|
Max. Speed
|
110 km/hr
|
Gradeability
|
27%
|
Frame Dimensions (mm)
|
|
Frame Width (front)
|
940
|
Frame With (Rear)
|
800
|
Frame Section Height
|
300
|
Frame Section Width
|
90
|
Section Thickness
|
8+5
|
Clutch
|
|
Type
|
Dry Singe Plate
|
Diameter
|
430 mm (17 inch)
|
Operating System
|
Hydraulic Control with Air booster, pulling
|
Engine
|
|
Make
|
Renault
|
Model
|
DC 11
|
Emission Level
|
Euro III
|
Max Power
|
385 HP/420 HP
|
Max Torque
|
1800Nm/2050 Nm
|
Displacement (lit)
|
11,120
|
No. of Cylinders
|
6
|
System
|
Water Cooled, Turbocharge, After Cooled,direct injection
|
Cylinder bore (mm)
|
123
|
Stroke (mm)
|
156
|
Gear Box / Transmission
|
|
Type
|
Fast 12JSD200TA
|
Number of Gears
|
12 forward Gears & 2 reverse syncronized.
|
Axles
|
|
Make
|
DANA
|
Front
|
Elliot type I beam section
|
Load Capacity
|
7 tons
|
Rear
|
Single reduction tandem axle, with axle lock
|
Load Capacity (ton)
|
26 Tons
|
Final Ratio
|
3.909
|
Load Capacity (ton)
|
10x2
|
Suspension
|
|
Front
|
Leaf Spring w. shock absorber and stabilizer bar.
|
Rear
|
Leaf Springs
|
Brake System
|
|
Service brakes
|
Full Air Brake System, split pneumatic circuit, Parking spring brake Acting rear axles, Engine exhaust brake, ABS & ADR specs
|
Fuel Tank
|
|
Type
|
Aum tank with lockable cap
|
Capacity
|
700 ltrs
|
Cabin
|
|
Cabin
|
Sleeper Cab, forward control type, low roof, new face, all welded steel cab, eletric cab tilting, front and rear mechanical cab suspension, adjustable driver's seat (mechanica suspension), air conditioning system, power windows, central locking, USB, mp3 player
|
Tyres
|
|
Front
|
Single
|
Rear
|
Dual
|
Size
|
12.00R20
|
5th Wheel
|
3.5" (90#) or fifth wheel 2.0 (50#)
|
Battery
|
|
Voltage (V)
|
24
|
Battery Capacity
|
165X2
|
Dongfeng DF420 PM 6x4 Prime Mover Specifications
Kerb Weight | 9000 KG | No of Doors | 2 doors |
Overall Height | 3770 mm / 12'5" feet | Overall Length | 6960 mm / 22'11" feet |
Overall Width | 2500 mm / 8'3" feet | Wheel Base | 3300+1350 mm / 10'10" feet |
Ground Clearance | - |
Cylinder Configuration | - | Displacement | 11120 cc |
Engine Power | 420 HP | Fuel System | Direct Injection |
Torque | 2050 Nm | Valve Mechanism | Turbocharged |
Valves per Cylinder | - | Compression Ratio | - |
Assembly | Local | Warranty | - |
No of Cylinders | 6 | Fuel Grade | - |
CO2 Emission | Euro III | Bore/stroke (mm) | 123/156 |
Minimum Turning Radius | - | Steering Type | |
Power Assisted | - | Steering Switch | - |
Tire / Tyre Size | 12.00R20 | Wheel Size | 20 in |
PCD | mm | Wheel Type |
Mileage City | 0 KM/LITER | Mileage Highway | KM/LITER |
Fuel Tank Capacity | 700 L |
Gearbox | 12-speed |
Suspension | Front: Leaf Springs with stabilizer, Rear: Leaf Springs | City driveability (20-80 kmph) | - |
Top Speed | 110 KM/H | Drive Modes | - |
Parking Sensors | - | Acceleration 0-100kmph | - |
Headlights | - | Day Time Running Lights (DRL) | - |
Brakes | Full Air Brake System, Parking spring brake ADR | Braking (100-0 kmph) | - |
Braking (80-0 kmph) | - |
