Millat MF 240 2025 Price in Pakistan & Specs

PKR 2,365,000

Get On-Road Price

Get This Vehicle Financed

Write a Review

New Millat MF

Used Millat MF

Engine

2500 cc

Horsepower

50 hp @ 2250 rpm

Torque

172 Nm @1400 rpm

Key Specifications of Millat MF 240

Fuel Type

Diesel

Max Power (hp@rpm)

50 hp @ 2250 rpm

Transmission Type

Manual

Body Type

Tractor

Drive Train

FWD

Key Features of Millat MF 240

Millat MF 240 Colors

Red

Millat MF 2023 Models

Millat MF 240 Brochure Specs and Features

See latest and brand new Millat MF 240 full specs with all the features in detail.

Performance
Engine power	50 (B.S) hp*@2,250
Torque	172 Nm@1,400 engine rpm
PTO Power	44 hp**@ engine speed
Engine
Type	Diesel /AD 3,1524
No. of cylinders	3
Injection	Direct
Bore	91.5 mm
Stroke	127.0 mm
Capacity (litres)	2.5
Compression ratio	16.5:1
Aspiration	Natural
Starting aid	Thermostart
Throttle control	Hand and foot
Cooling	Water
Air Cleaner Type	Oil bath
Air Pre-Cleaner	Over bonnet
Fuel filter	Dual, high capacity
Exhaust	Vertical
Electrics
Voltage	12V, Negative Earth
Battery	118 Ah
Starter Motor	2.2 kW
Alternator	32 Amp.
Clutch
Type	Dual clutch
Diameter	305x254 mm
Transmission
Type	Sliding spur
Number of gears	8 forward 2 revers
Gear	Speed (km/hr)
Forward 1 (first low)	2.5
Forward 2	3.7
Forward 3	5.0
Forward 4	6.7
Forward 5 (first high)	10.0
Forward 6	14.7
Forward 7	20.1
Forward 8	27.0
Revers 1 (low)	3.4
Revers 2 (high) Power Take Off	13.6
Type	Live
Engine speed	1,789 rpm@ 540 PTO rpm
Shaft diameter	35 mm
No. of splines	6
hydraulics
Functions	Draft control, Position control, Response Control, Constant pumping
Pump Type	Reciprocating Ferguson Pump
Oil Flow	162/ min
Pressure	19.2 Mpa
Lift capacity with lower links horizontal	1,415 kg
Lower links	With cat . I & II interchaneable balls
Front Axle
Type	Box Section, Adjustable
Steering
Steering	Manual
REAR AXLE AND BRAKES
Brake Type	Outboard drum brakes
Actuation	Mechanical, Independent or locked together
Parking Brake	Hand lever operated
Differential lock	Mechanical
Instrumentation
Gauges	Tachometer, Hourmeter, Fuel level, Battery condition & Water temperature
Warning lights	Direction Indecators, battery charge,headlight main beam,low engine oil pressure,brake lights & auxiliaty socket
Tyres
Front	6.00-16(6rp)
Rear	12.4/11-28 (6 Rp)
TRACK ADJUSTMENT
Front	1,245 - 1,854 mm
Rear	1,219 - 1,930 mm
*WEIGHTS AND DIMENSIONS ()**
Weight
Gross Weight	1,650 kg
Dimensions
Wheel base	1,892mm
Overall length	3,260mm
Overall width (min)	1,651mm
Height
Over exhaust	2,145mm
Over steering wheel	1,410mm
Turning circle
With brakes	5,560mm
Without brakes	6,200mm
Ground Clearance
(Under gear box)	338 mm
Capacities
Fuel Tank	47.5
Engine sump	6.8
Cooling system	10.2
Hydraulic system	33.0
Steering box	0.9
oil bath air - cleaner	0.65
STANDARD EQUIPMENT
STANDARD EQUIPMENT	Weight frame without weights, Standard tool box with set of tools, Top link, Top link end Cat! & II balls, Check Chains, Spring suspension seat, Flat top fenders & Operator’s and service manual.
OPTIONAL EQUIPMENT
OPTIONAL EQUIPMENT	Front end weights, Swinging drawbar, Sun Canopy, Pintle Hook and 9 Hole drawbar.

Show More ▼Show Less ▲

Millat MF 240 Specifications

Kerb Weight	1415 KG	No of Doors	0 doors
Overall Height	mm / 0'0" feet	Overall Length	3260 mm / 10'9" feet
Overall Width	1651 mm / 5'5" feet	Wheel Base	1892 mm / 6'3" feet
Ground Clearance	338 mm / 1'2" feet

Cylinder Configuration	-	Displacement	2500 cc
Engine Power	50 hp @ 2250 rpm	Fuel System	-
Torque	172 Nm @1400 rpm	Valve Mechanism	-
Valves per Cylinder	-	Compression Ratio	16.5
Assembly	Local	Warranty	-
No of Cylinders	3	Fuel Grade	-
CO2 Emission	-	Bore/stroke (mm)	91.5 x 127

Minimum Turning Radius	-	Steering Type	Manual
Power Assisted	-	Steering Switch	-

Tire / Tyre Size		Wheel Size	in
PCD	mm	Wheel Type

Mileage City	0 KM/LITER	Mileage Highway	KM/LITER

Fuel Tank Capacity	48 L

Gearbox	10-speed

Suspension	-	City driveability (20-80 kmph)	-

Top Speed	-	Drive Modes	-
Parking Sensors	-	Acceleration 0-100kmph	-
Headlights	-	Day Time Running Lights (DRL)	-

Brakes	-	Braking (100-0 kmph)	-
Braking (80-0 kmph)	-

Drive Type	Front/Four wheel drive	Drive Setup	Driver right
Brochure	Download	Waiting Time (Own)	-
Release Date	8 February 2023	Category	Work Related
Outer Door handle finish	-	Door Visor
Multi Information Combination	-	Seats, Armrests & Door Lining Inserts	-
Interior Color	-	Insight Door Handles	-
AC Vent Knobs	-	Hand Brake Knob	-
Antenna	-	Inner Lights	-
Supervision Cluster / Driver Multi Information System	-

Sound System / Speakers	-	USB Charger	-
Infotainment / Funtainment System / Audio System	-
Axels	-	Licensed Weight	-

Comfort & Convenience

CoolBox	Cup Holders
Power Seats / Seat Adjustment	Remote Boot/Fuel-Lid
Steering Adjustment	Sun-Roof \| Moon-Roof	\|
Cruise Control	Keyless Entry
Power Mirror	Remote Keyless Entry
Heated Seats	USB and Auxillary Cable
Climate Control	Rear AC Vents
Steering Switches	Arm Rest
Multi Info	Optional Navigation
Vanity Mirror	Accessory Power Outlet
Seat Lumbar Support	Smart Access Card Entry
Voice Control	Steering Wheel Gearshift Paddles
Central Console Armrest	Tailgate Ajar Indicator / Trunk Warning
Power Windows	Wiper Tinted Glass
Traffic Jam Assist	Navigation System / GPS System
Rear Ventilation	Terrain Response System
Air Conditioner	Remote Trunk Opener / Tailgate
Fast Charging	Auto door lock with speed
Brake Override System (BOS) / Smart pedal	Smart Entry
Auto A/C	Wifi Hotspot
Voice Command	Dust & Pollen Air Filter / Air Purifier
Digital Clock	Outside Temperature Display
Smart Welcome System	Refrigerator Compartment
Cabin Watch	Cabin Talk
Adaptive Cruise Control	Lane Winker
Remote Windows / Smart Key Open Close

Interior

Defogger		Tachometer
Third Row Seats		Defogger
Rear Window Defroster		Folding Rear-Seat
Leather Interior		Rear Seat Headrest
Heater		Interior Lighting
Isofix Seat/ Child Seat		Front Map Lamps

Exterior

Alloy Rims		Leather Seats
Front Fog Lights		Leather Seats
Alloy Rims		Rear Window Wiper
Front Fog Lights		Adjustable Headlights / Headlights Leveling
Auto Wiper / Rain Sensing Wiper		Power Antenna
Removable/Convertible Top		Roof Carrier
Side Stepper		Outside Rear View Mirror Turn Indicators
Integrated Antenna		Chrome Grille
Tow Package		Chrome Garnish
Smoke Headlamps		Roof Rail
Heated Wing Mirror		Rear Spoiler
Outside Mirror		Spare wheel
Trunk LID Lining

Safety

Power Door Locks		Alarm System Anti-Lock
Brakes Fog lights		Immobilizer Key
Traction Control System TCS		Child Lock
Rear Power Windows / Electric Windows		Automatic Emergency Braking
Intelligent Speed Assist System		Lane Departure Warning
Rear Seat Belts		Electronic Brake Assist EBA
Tyre Pressure Monitor System RPMS		Vehicle Stability Control
Anti-Theft Device		Central Locking
Speed Alert		Crash Sensor
Hill Assist / Hill Hold Control / Downhill Brake Control (HHC/ HAC / DBC)		Anti-Pinch Power Windows
Blind Spot Monitor		Security System
Hill Descent Control		Automatic Headlamps/ Automatic Headlights
High Mount Stop Lamp		Electronic Parking Brake
Vehicle Stability Management		Driver Condition Monitor
Wade Sensing		Rear Pre-collision Monitor
3D Surround Camera		Road Sign Assist
Vehicle Running Recorder / Trip Recorder
